USB Registers
www.ti.com
16.5.7.1106 QUEUE_149_STATUS_A Register (offset = 3950h) [reset = 0h]
QUEUE_149_STATUS_A is shown in Figure 16-1382 and described in Table 16-1396.
Figure 16-1382. QUEUE_149_STATUS_A Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved QUEUE_ENTRY_COUNT
R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-1396. QUEUE_149_STATUS_A Register Field Descriptions
Bit Field Type Reset Description
13-0 QUEUE_ENTRY_COUNT R-0 0 This field indicates how many packets are currently queued on the
queue.
Queue Manager Queue N Status Registers A
3214
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
