UART Registers

www.ti.com

19.5.1.50 ISR2 Register

The ISR2 register displays the status of RX/TX FIFOs empty corresponding interrupts. The ISR2 register

(ISR2) is shown in Figure 19-79 and described in Table 19-78.

Figure 19-83. ISR2 Register

31 1 0

Reserved TXFIFO_EMPT RXFIFO_EMPT

Y_STS Y_STS

R-0 R/W-0 R/W-0

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 19-82. ISR2 Register Field Descriptions

Bit Field Value Description

31-2 Reserved 0 Reserved.

1 TXFIFO_EMPTY_ 0 TXFIFO_EMPTY interrupt not pending.

STS

1 TXFIFO_EMPTY interrupt pending.

0 RXFIFO_EMPTY 0 RXFIFO_EMPTY interrupt not pending.

_STS

1 RXFIFO_EMPTY interrupt pending.

3546

Universal Asynchronous Receiver/Transmitter (UART) SPRUH73H–October 2011–Revised April 2013
