Touchscreen Controller Registers
12.5.1.57 FIFO0DATA Register (offset = 100h) [reset = 0h]
FIFO0DATA is shown in Figure 12-61 and described in Table 12-61.
ADC_ FIFO0 _READ Data @TSC_ADC_SS_FIFO0 READ Register
Figure 12-61. FIFO0DATA Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved ADCCHNLID
R-0h R-0h
15 14 13 12 11 10 9 8
Reserved ADCDATA
R-0h R-0h
7 6 5 4 3 2 1 0
ADCDATA
R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-61. FIFO0DATA Register Field Descriptions
Bit Field Type Reset Description
31-20 Reserved R 0h
RESERVED.
19-16 ADCCHNLID R 0h Optional ID tag of channel that captured the data.
If tag option is disabled, these bits will be 0.
15-12 Reserved R 0h
11-0 ADCDATA R 0h
12 bit sampled ADC converted data value stored in FIFO 0.
1095
SPRUH73H–October 2011–Revised April 2013 Touchscreen Controller
