Power, Reset, and Clock Management
8.1.12.2.28 CM_AUTOIDLE_DPLL_PER Register (offset = 6Ch) [reset = 0h]
CM_AUTOIDLE_DPLL_PER is shown in Figure 8-111 and described in Table 8-119.
This register provides automatic control over the DPLL activity.
Figure 8-111. CM_AUTOIDLE_DPLL_PER Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved AUTO_DPLL_MODE
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 8-119. CM_AUTOIDLE_DPLL_PER Register Field Descriptions
Bit Field Type Reset Description
31-3 Reserved R 0h
2-0 AUTO_DPLL_MODE R/W 0h
AUTO_DPLL_MODE is not supported.
