Page #1320 background imageLoading...
Page #1320 background image
Ethernet Subsystem Registers
www.ti.com
14.5.3.11 CPTS_EVENT_HIGH Register (offset = 38h) [reset = 0h]
CPTS_EVENT_HIGH is shown in Figure 14-88 and described in Table 14-100.
UPPER 32-BITS OF THE EVENT VALUE
Figure 14-88. CPTS_EVENT_HIGH Register
31 30 29 28 27 26 25 24
Reserved PORT_NUMBER
R-0h R-0h
23 22 21 20 19 18 17 16
EVENT_TYPE MESSAGE_TYPE
R-0h R-0h
15 14 13 12 11 10 9 8
SEQUENCE_ID
R-0h
7 6 5 4 3 2 1 0
SEQUENCE_ID
R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-100. CPTS_EVENT_HIGH Register Field Descriptions
Bit Field Type Reset Description
31-29 Reserved R 0h
28-24 PORT_NUMBER R 0h
Port Number - indicates the port number of an ethernet event or the
hardware push pin number (1 to 4).
23-20 EVENT_TYPE R 0h Time Sync Event Type
0000 - Time Stamp Push Event
0001 - Time Stamp Rollover Event
0010 - Time Stamp Half Rollover Event
0011 - Hardware Time Stamp Push Event
0100 - Ethernet Receive Event
0101 - Ethernet Transmit Event
19-16 MESSAGE_TYPE R 0h Message type - The message type value that was contained in an
ethernet transmit or receive time sync packet.
This field is valid only for ethernet transmit or receive events.
15-0 SEQUENCE_ID R 0h Sequence ID - The
16-bit sequence id is the value that was contained in an ethernet
transmit or receivetime sync packet.
This field is valid only for ethernet transmit or receive events.
