USB Registers www.ti.com
16.5.3.14 USB1RXMODE Register (offset = 74h) [reset = 0h]
USB1RXMODE is shown in Figure 16-112 and described in Table 16-122.
Figure 16-112. USB1RXMODE Register
31 30 29 28 27 26 25 24
Reserved RX15_MODE RX14_MODE RX13_MODE
R/W-0h R/W-0h R/W-0h
23 22 21 20 19 18 17 16
RX12_MODE RX11_MODE RX10_MODE RX9_MODE
R/W-0h R/W-0h R/W-0h R/W-0h
15 14 13 12 11 10 9 8
RX8_MODE RX7_MODE RX6_MODE RX5_MODE
R/W-0h R/W-0h R/W-0h R/W-0h
7 6 5 4 3 2 1 0
RX4_MODE RX3_MODE RX2_MODE RX1_MODE
R/W-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-122. USB1RXMODE Register Field Descriptions
Bit Field Type Reset Description
29-28 RX15_MODE R/W 0h 00: Transparent Mode on RX endpoint 14
01: RNDIS Mode on RX endpoint 14
10: CDC Mode on RX endpoint 14
11: Generic RNDIS or Infinite Mode on RX endpoint 14
27-26 RX14_MODE R/W 0h 00: Transparent Mode on RX endpoint 13
01: RNDIS Mode on RX endpoint 13
10: CDC Mode on RX endpoint 13
11: Generic RNDIS or Infinite Mode on RX endpoint 13
25-24 RX13_MODE R/W 0h 00: Transparent Mode on RX endpoint 12
01: RNDIS Mode on RX endpoint 12
10: CDC Mode on RX endpoint 12
11: Generic RNDIS or Infinite Mode on RX endpoint 12
23-22 RX12_MODE R/W 0h 00: Transparent Mode on RX endpoint 11
01: RNDIS Mode on RX endpoint 11
10: CDC Mode on RX endpoint 11
11: Generic RNDIS or Infinite Mode on RX endpoint 11
21-20 RX11_MODE R/W 0h 00: Transparent Mode on RX endpoint 10
01: RNDIS Mode on RX endpoint 10
10: CDC Mode on RX endpoint 10
11: Generic RNDIS or Infinite Mode on RX endpoint 10
19-18 RX10_MODE R/W 0h 00: Transparent Mode on RX endpoint 9
01: RNDIS Mode on RX endpoint 9
10: CDC Mode on RX endpoint 9
11: Generic RNDIS or Infinite Mode on RX endpoint 9
17-16 RX9_MODE R/W 0h 00: Transparent Mode on RX endpoint 8
01: RNDIS Mode on RX endpoint 8
10: CDC Mode on RX endpoint 8
11: Generic RNDIS or Infinite Mode on RX endpoint 8
15-14 RX8_MODE R/W 0h 00: Transparent Mode on RX endpoint 7
01: RNDIS Mode on RX endpoint 7
10: CDC Mode on RX endpoint 7
11: Generic RNDIS or Infinite Mode on RX endpoint 7
13-12 RX7_MODE R/W 0h 00: Transparent Mode on RX endpoint 6
01: RNDIS Mode on RX endpoint 6
10: CDC Mode on RX endpoint 6
11: Generic RNDIS or Infinite Mode on RX endpoint 6
1878
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
