CONTROL_MODULE Registers
www.ti.com
9.3.36 hw_event_sel_grp2 Register (offset = 694h) [reset = 0h]
hw_event_sel_grp2 is shown in Figure 9-39 and described in Table 9-46.
Figure 9-39. hw_event_sel_grp2 Register
31 30 29 28 27 26 25 24
event8
R/W-0h
23 22 21 20 19 18 17 16
event7
R/W-0h
15 14 13 12 11 10 9 8
event6
R/W-0h
7 6 5 4 3 2 1 0
event5
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-46. hw_event_sel_grp2 Register Field Descriptions
Bit Field Type Reset Description
31-24 event8 R/W 0h Select 8th trace event from group 2
23-16 event7 R/W 0h Select 7th trace event from group 2
15-8 event6 R/W 0h Select 6th trace event from group 2
7-0 event5 R/W 0h Select 5th trace event from group 2
800
Control Module SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
