20.3.5.11 ALARM_DAYS_REG Register (offset = 2Ch) [reset = 1h]
ALARM_DAYS_REG is shown in Figure 20-71 and described in Table 20-74.
The ALARM_DAYS_REG is used to program the day of the month value for the alarm interrupt. Days are
stored as BCD format. In BCD format, the decimal numbers 0 through 9 are encoded with their binary
equivalent.
Figure 20-71. ALARM_DAYS_REG Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved ALARM_DAY1 ALARM_DAY0
R-0h R/W-0h R/W-1h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 20-74. ALARM_DAYS_REG Register Field Descriptions
Bit Field Type Reset Description
31-6 Reserved R 0h
5-4 ALARM_DAY1 R/W 0h
2nd digit for days, Range from 0 to 3
3-0 ALARM_DAY0 R/W 1h
1st digit for days, Range from 0 to 9
3644
Timers SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
