Texas Instruments AM335 Series Technical Reference Manual

www.ti.com I2C Registers
21.4.1.7 I2C_IRQENABLE_CLR Register (offset = 30h) [reset = 0h]
I2C_IRQENABLE_CLR is shown in Figure 21-22 and described in Table 21-15.
All 1-bit fields clear a specific interrupt event. Writing a 1 to a bit will disable the interrupt field. Writing a 0
will have no effect, that is, the register value will not be modified. For all the internal fields of the
I2C_IRQENABLE_CLR register, the descriptions given in the I2C_IRQSTATUS_RAW subsection are
valid.
Figure 21-22. I2C_IRQENABLE_CLR Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved XDR_IE RDR_IE Reserved ROVR XUDF AAS_IE BF_IE
R-0h R/W-0h R/W-0h R-0h R/W-0h R/W-0h R/W-0h R/W-0h
7 6 5 4 3 2 1 0
AERR_IE STC_IE GC_IE XRDY_IE RRDY_IE ARDY_IE NACK_IE AL_IE
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 21-15. I2C_IRQENABLE_CLR Register Field Descriptions
Bit Field Type Reset Description
31-15 Reserved R 0h
14 XDR_IE R/W 0h Transmit draining interrupt enable clear.
Mask or unmask the interrupt signaled by bit in I2C_STAT[XDR].
0x0 = Transmit draining interrupt disabled
0x1 = Transmit draining interrupt enabled
13 RDR_IE R/W 0h Receive draining interrupt enable clear.
Mask or unmask the interrupt signaled by bit in I2C_STAT[RDR].
0x0 = Receive draining interrupt disabled
0x1 = Receive draining interrupt enabled
12 Reserved R 0h
11 ROVR R/W 0h
Receive overrun enable clear.
0x0 = Receive overrun interrupt disabled
0x1 = Receive draining interrupt enabled
10 XUDF R/W 0h
Transmit underflow enable clear.
0x0 = Transmit underflow interrupt disabled
0x1 = Transmit underflow interrupt enabled
9 AAS_IE R/W 0h Addressed as slave interrupt enable clear.
Mask or unmask the interrupt signaled by bit in I2C_STAT[AAS].
0x0 = Addressed as slave interrupt disabled
0x1 = Addressed as slave interrupt enabled
8 BF_IE R/W 0h Bus Free interrupt enable clear.
Mask or unmask the interrupt signaled by bit in I2C_STAT[BF].
0x0 = Bus free interrupt disabled
0x1 = Bus free interrupt enabled
7 AERR_IE R/W 0h Access error interrupt enable clear.
Mask or unmask the interrupt signaled by bit in I2C_STAT[AERR].
0x0 = Access error interrupt disabled
0x1 = Access error interrupt enabled
3731
SPRUH73H–October 2011–Revised April 2013 I2C
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
