Ethernet Subsystem Registers
14.5.9.5 C0_RX_THRESH_EN Register (offset = 10h) [reset = 0h]
C0_RX_THRESH_EN is shown in Figure 14-201 and described in Table 14-219.
SUBSYSTEM CORE 0 RECEIVE THRESHOLD INT ENABLE REGISTER
Figure 14-201. C0_RX_THRESH_EN Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
C0_RX_THRESH_EN
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-219. C0_RX_THRESH_EN Register Field Descriptions
Bit Field Type Reset Description
31-8 Reserved R 0h
7-0 C0_RX_THRESH_EN R/W 0h Core 0 Receive Threshold Enable - Each bit in this register
corresponds to the bit in the receive threshold interrupt that is
enabled to generate an interrupt on C0_RX_THRESH_PULSE.
1443
SPRUH73H–October 2011–Revised April 2013 Ethernet Subsystem
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
