Ethernet Subsystem Registers
14.5.8.11 VLAN_LTYPE Register (offset = 28h) [reset = 81008100h]
VLAN_LTYPE is shown in Figure 14-194 and described in Table 14-211.
LTYPE1 AND LTYPE 2 REGISTER
Figure 14-194. VLAN_LTYPE Register
31 30 29 28 27 26 25 24
VLAN_LTYPE2
R/W-0
23 22 21 20 19 18 17 16
VLAN_LTYPE2
R/W-0
15 14 13 12 11 10 9 8
VLAN_LTYPE1
R/W-0
7 6 5 4 3 2 1 0
VLAN_LTYPE1
R/W-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-211. VLAN_LTYPE Register Field Descriptions
Bit Field Type Reset Description
31-16 VLAN_LTYPE2 R/W-0 0 Time Sync VLAN LTYPE2 This VLAN LTYPE value is used for tx
and rx.
This is the inner VLAN if both are present.
15-0 VLAN_LTYPE1 R/W-0 0 Time Sync VLAN LTYPE1 This VLAN LTYPE value is used for tx
and rx.
This is the outer VLAN if both are present.
1435
SPRUH73H–October 2011–Revised April 2013 Ethernet Subsystem
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
