7.3.5.25 IRQSTATUS_RAW_SYS Register (offset = A4h) [reset = 0h]
IRQSTATUS_RAW_SYS is shown in Figure 7-115 and described in Table 7-135.
Figure 7-115. IRQSTATUS_RAW_SYS Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved Reserved reg_ta_sys reg_err_sys
R-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 7-135. IRQSTATUS_RAW_SYS Register Field Descriptions
Bit Field Type Reset Description
31-3 Reserved R 0h
2 Reserved R/W 0h
Reserved.
1 reg_ta_sys R/W 0h Raw status of system OCP interrupt.
Write 1 to set the (raw) status, mostly for debug.
Writing a 0 has no effect.
0 reg_err_sys R/W 0h Raw status of system OCP interrupt.
Write 1 to set the (raw) status, mostly for debug.
Writing a 0 has no effect.
