Introduction
18.1 Introduction
18.1.1 MMCHS Features
The general features of the MMCHS host controller IP are:
• Built-in 1024-byte buffer for read or write
• Two DMA channels, one interrupt line
• Clock support
– 96-MHz functional clock source input
– up to 384Mbit/sec (48MByte/sec) in MMC mode 8-bit data transfer
– up to 192Mbit/sec (24MByte/sec) in High-Speed SD mode 4-bit data transfer
– up to 24Mbit/sec (3MByte/sec) in Default SD mode 1-bit data transfer
• Support for SDA 3.0 Part A2 programming model
• Serial link supports full compliance with:
– MMC command/response sets as defined in the MMC standard specification v4.3.
– SD command/response sets as defined in the SD Physical Layer specification v2.00
– SDIO command/response sets and interrupt/read-wait suspend-resume operations as defined in
the SD part E1 specification v 2.00
– SD Host Controller Standard Specification sets as defined in the SD card specification Part A2
v2.00
18.1.2 Unsupported MMCHS Features
The MMCHS module features not supported in this device are shown in Table 18-1.
Table 18-1. Unsupported MMCHS Features
Feature Reason
MMC Out-of-band interrupts MMC_OBI input tied low
Master DMA operation Disabled through synthesis parameter
Card Supply Control (MMCHS(1-2)) Signal not pinned out
Dual Data Rate (DDR) mode Timing not supported
3345
SPRUH73H–October 2011–Revised April 2013 Multimedia Card (MMC)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
