9.3.48 bb_scale Register (offset = 7D0h) [reset = 0h]
bb_scale is shown in Figure 9-51 and described in Table 9-58.
Figure 9-51. bb_scale Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved scale
R-0h R-0h
7 6 5 4 3 2 1 0
Reserved bbias
R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-58. bb_scale Register Field Descriptions
Bit Field Type Reset Description
31-12 Reserved R 0h
11-8 scale R 0h Dynamic core voltage scaling for class 0
7-2 Reserved R 0h
1-0 bbias R 0h BBIAS value from Efuse
