Ethernet Subsystem Registers
www.ti.com
14.5.2.5 RX_CONTROL Register (offset = 14h) [reset = 0h]
RX_CONTROL is shown in Figure 14-33 and described in Table 14-44.
CPDMA_REGS RX CONTROL REGISTER
Figure 14-33. RX_CONTROL Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved RX_EN
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-44. RX_CONTROL Register Field Descriptions
Bit Field Type Reset Description
31-1 Reserved R 0h
0 RX_EN R/W 0h RX DMA Enable
0 - Disabled
1 - Enabled
1262
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
