14.5.10.14 MDIO User PHY Select Register 1 (MDIOUSERPHYSEL1)
The MDIO user PHY select register 1 (MDIOUSERPHYSEL1) is shown in Figure 14-245 and described in
Table 14-264.
Figure 14-245. MDIO User PHY Select Register 1 (MDIOUSERPHYSEL1)
31 16
Reserved
R-0x0
15 8 7 6 5 4 0
Reserved LINKSEL LINKINTENB Reserved PHYADDRMON
R-0x0 R/W-0x0 R/W-0x0 R-0x0 R/W-0x0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-264. MDIO User PHY Select Register 1 (MDIOUSERPHYSEL1) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved.
7 LINKSEL 0-1 Link status determination select. Set to 1 to determine link status using the
MLINK pin. Default value is 0 which implies that the link status is determined by
the MDIO state machine.
6 LINKINTENB Link change interrupt enable. Set to 1 to enable link change status interrupts for
PHY address specified in PHYADDRMON. Link change interrupts are disabled
if this bit is cleared to 0.
0 Link change interrupts are disabled
1 Link change status interrupts for PHY address specified in PHYADDRMON bits
are enabled.
5 Reserved 0 Reserved.
4-0 PHYADDRMON 0-1Fh PHY address whose link status is to be monitored.
