EDMA3 Registers
www.ti.com
11.4.1.8.4 QDMA Event Enable Set Register (QEESR)
The QDMA event enable register (QEER) cannot be modified by directly writing to the register, to ease the
software burden when multiple tasks are attempting to simultaneously modify these registers. The QDMA
event enable set register (QEESR) is used to enable events. Writes of 1 to the bits in QEESR set the
corresponding QDMA channel bits in QEER; writes of 0 have no effect.
The QEESR is shown in Figure 11-102 and described in Table 11-86.
Figure 11-102. QDMA Event Enable Set Register (QEESR)
31 16
Reserved
R-0
15 7 6 5 4 3 2 1 0
Reserved E7 E6 E5 E4 E3 E2 E1 E0
R-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
LEGEND: R = Read only; W = Write only; -n = value after reset
Table 11-86. QDMA Event Enable Set Register (QEESR) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved. Always write 0 to this bit; writes of 1 to this bit are not supported and attempts to do so may
result in undefined behavior.
7-0 En QDMA event enable set for channels 0-7.
0 No effect.
1 QDMA event is enabled. Corresponding bit in the QDMA event enable register (QEER) is set (En = 1).
990
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
