14.5.8.2 CONTROL Register (offset = 4h) [reset = 0h]
CONTROL is shown in Figure 14-185 and described in Table 14-202.
SWITCH CONTROL REGISTER
Figure 14-185. CONTROL Register
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8
Reserved
7 6 5 4 3 2 1 0
Reserved DLR_EN RX_VLAN_ENCAP VLAN_AWARE FIFO_LOOPBACK
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-202. CONTROL Register Field Descriptions
Bit Field Type Reset Description
3 DLR_EN R/W-0 0 DLR enable
0 - DLR is disabled.
DLR packets will not be moved to queue priority 3 and will not be
separated out onto dlr_cpdma_ch.
1 - DLR is disabled.
DLR packets be moved to destination port transmit queue priority 3
and will be separated out onto dlr_cpdma_ch when packet is to
egress on port 0.
2 RX_VLAN_ENCAP R/W-0 0 Port 0 VLAN Encapsulation (egress):
0 - Port 2 receive packets (from 3G) are not VLAN encapsulated.
1 - Port 2 receive packets (from 3G) are VLAN encapsulated.
1 VLAN_AWARE R/W-0 0 VLAN Aware Mode:
0 - 3G is in the VLAN unaware mode.
1 - 3G is in the VLAN aware mode.
0 FIFO_LOOPBACK R/W-0 0 FIFO Loopback Mode
0 - Loopback is disabled
1 - FIFO Loopback mode enabled.
Each packet received is turned around and sent out on the same
port's transmit path.
Port 2 receive is fixed on channel zero.
The RXSOFOVERRUN statistic will increment for every packet sent
in FIFO loopback mode.
1426
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
