www.ti.com
Ethernet Subsystem Registers
14.5.9.3 CONTROL Register (offset = 8h) [reset = 0h]
CONTROL is shown in Figure 14-199 and described in Table 14-217.
SUBSYSTEM CONTROL REGISTER
Figure 14-199. CONTROL Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved MMR_STDBYMODE MMR_IDLEMODE
R-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-217. CONTROL Register Field Descriptions
Bit Field Type Reset Description
31-4 Reserved R 0h
3-2 MMR_STDBYMODE R/W 0h Configuration of the local initiator state management mode.
By definition, initiator may generate read/write transaction as long as
it is out of STANDBY state.
0x0 = Force-standby mode : Local initiator is unconditionally placed
in standbystate.
0x1 = No-standby mode : Local initiator is unconditionally placed out
of standby state.
0x2 = Reserved : Reserved.
0x3 = Reserved : Reserved.
1-0 MMR_IDLEMODE R/W 0h Configuration of the local initiator state management mode.
By definition, initiator may generate read/write transaction as long as
it is out of IDLE state.
0x0 = Force-idle mode : Local initiator is unconditionally placed in
idle state.
0x1 = No-idle mode : Local initiator is unconditionally placed out of
idle state.
0x2 = Reserved : Reserved.
0x3 = Reserved : Reserved.
1441
SPRUH73H–October 2011–Revised April 2013 Ethernet Subsystem
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
