www.ti.com Multimedia Card Registers
18.5.1.13 SD_RSP54 Register (offset = 218h) [reset = 0h]
SD_RSP54 is shown in Figure 18-49 and described in Table 18-32.
This 32-bit register holds bits positions [95:64] of command response type R2.
Figure 18-49. SD_RSP54 Register
31 30 29 28 27 26 25 24
RSP5
R-0h
23 22 21 20 19 18 17 16
RSP5
R-0h
15 14 13 12 11 10 9 8
RSP4
R-0h
7 6 5 4 3 2 1 0
RSP4
R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 18-32. SD_RSP54 Register Field Descriptions
Bit Field Type Reset Description
31-16 RSP5 R 0h Command Response
[95:80]
15-0 RSP4 R 0h Command Response
[79:64]
3413
