www.ti.com
ELM
7.4.5 ELM Registers
Table 7-174. ELM Registers
Address Offset Acronym Description Section
0h ELM_REVISION ELM Revision Register Section 7.4.5.1
10h ELM_SYSCONFIG ELM System Configuration Register Section 7.4.5.2
14h ELM_SYSSTATUS ELM System Status Register Section 7.4.5.3
18h ELM_IRQSTATUS ELM Interrupt Status Register Section 7.4.5.4
1Ch ELM_IRQENABLE ELM Interrupt Enable Register Section 7.4.5.5
20h ELM_LOCATION_CONFIG ELM Location Configuration Register Section 7.4.5.6
80h ELM_PAGE_CTRL ELM Page Definition Register Section 7.4.5.7
400h + ELM_SYNDROME_FRAGMENT_0_i
ELM_SYNDROME_FRAGMENT_0_i
(1)
Section 7.4.5.8
(40h × i) Register
404h+ ELM_SYNDROME_FRAGMENT_1_i
ELM_SYNDROME_FRAGMENT_1_i Section 7.4.5.9
(40h × i) Register
408h + ELM_SYNDROME_FRAGMENT_2_i
ELM_SYNDROME_FRAGMENT_2_i Section 7.4.5.10
(40h × i) Register
40Ch + ELM_SYNDROME_FRAGMENT_3_i
ELM_SYNDROME_FRAGMENT_3_i Section 7.4.5.11
(40h × i) Register
410h + ELM_SYNDROME_FRAGMENT_4_i
ELM_SYNDROME_FRAGMENT_4_i Section 7.4.5.12
(40h × i) Register
414h + ELM_SYNDROME_FRAGMENT_5_i
ELM_SYNDROME_FRAGMENT_5_i Section 7.4.5.13
(40h × i) Register
418h + ELM_SYNDROME_FRAGMENT_6_1
ELM_SYNDROME_FRAGMENT_6_1 Section 7.4.5.14
(40h × i) Register
800h +
ELM_LOCATION_STATUS_i ELM_LOCATION_STATUS_i Register Section 7.4.5.15
(100h × i)
880h-8BCh + ELM_ERROR_LOCATION_0-15_i
ELM_ERROR_LOCATION_0-15_i Section 7.4.5.16
(100h × i) Registers
(1)
i = 0 to 8
487
SPRUH73H–October 2011–Revised April 2013 Memory Subsystem
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
