Table 7-173. Use Case: Page Mode (continued)
Step Register/ Bit Field / Programming Model Value
Read the process exit status for syndrome ELM_LOCATION_STATUS_i[8] ECC_CORRECTABLE 0x1
polynomial 2: (i=2)
All errors were successfully located.
Read the process exit status for syndrome ELM_LOCATION_STATUS_i[8] ECC_CORRECTABLE 0x1
polynomial 3: (i=3)
All errors were successfully located.
Read the number of errors for syndrome ELM_LOCATION_STATUS_i[4:0] ECC_NB_ERRORS 0x4
polynomial 0: (i=0)
4 errors detected.
Read the number of errors for syndrome ELM_LOCATION_STATUS_i[4:0] ECC_NB_ERRORS 0x2
polynomial 1: (i=1)
2 errors detected.
Read the number of errors for syndrome ELM_LOCATION_STATUS_i[4:0] ECC_NB_ERRORS 0x1
polynomial 2: (i=2)
1 error detected.
Read the number of errors for syndrome ELM_LOCATION_STATUS_i[4:0] ECC_NB_ERRORS 0x0
polynomial 3: (i=3)
0 errors detected.
Read the error-location bit addresses for syndrome ELM_ERROR_LOCATION_0_i (i=0) 0x1FE
polynomial 0 of the 4 first registers:
ELM_ERROR_LOCATION_1_i (i=0) 0x617
ELM_ERROR_LOCATION_2_i (i=0) 0x650
ELM_ERROR_LOCATION_3_i (i=0) 0xA83
Read the error-location bit addresses for syndrome ELM_ERROR_LOCATION_0_i (i=1) 0x4
polynomial 1 of the 2 first registers:
ELM_ERROR_LOCATION_1_i (i=1) 0x1036
Read the errors location bit addresses for ELM_ERROR_LOCATION_0_i (i=1) 0x3E8
syndrome polynomial 2 of the first registers:
Clear the ELM_IRQSTATUS register. ELM_IRQSTATUS 0x1FF
