LCD Registers
www.ti.com
13.5.17 LCDDMA_FB0_BASE Register (offset = 44h) [reset = 0h]
LCDDMA_FB0_BASE is shown in Figure 13-35 and described in Table 13-30.
Figure 13-35. LCDDMA_FB0_BASE Register
31 30 29 28 27 26 25 24
fb0_base
R/W-0h
23 22 21 20 19 18 17 16
fb0_base
R/W-0h
15 14 13 12 11 10 9 8
fb0_base
R/W-0h
7 6 5 4 3 2 1 0
fb0_base Reserved
R/W-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 13-30. LCDDMA_FB0_BASE Register Field Descriptions
Bit Field Type Reset Description
31-2 fb0_base R/W 0h
Frame Buffer 0 Base Address pointer
1-0 Reserved R 0h
1148
LCD Controller SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
