Pulse-Width Modulation Subsystem (PWMSS)
www.ti.com
15.1.3.3 CLKCONFIG Register (offset = 8h) [reset = 111h]
CLKCONFIG is shown in Figure 15-4 and described in Table 15-8.
The clock configuration register is used in the PWMSS submodule for clkstop req and clk_en control.
Figure 15-4. CLKCONFIG Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved ePWMCLKSTOP_RE ePWMCLK_EN
Q
R-0h R/W-0h R/W-1h
7 6 5 4 3 2 1 0
Reserved eQEPCLKSTOP_REQ eQEPCLK_EN Reserved eCAPCLKSTOP_REQ eCAPCLK_EN
R-0h R/W-0h R/W-1h R-0h R/W-0h R/W-1h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 15-8. CLKCONFIG Register Field Descriptions
Bit Field Type Reset Description
31-10 Reserved R 0h
9 ePWMCLKSTOP_REQ R/W 0h
This bit controls the clkstop_req input to the ePWM module.
8 ePWMCLK_EN R/W 1h
This bit controls the clk_en input to the ePWM module.
7-6 Reserved R 0h
5 eQEPCLKSTOP_REQ R/W 0h
This bit controls the clkstop_req input to the eQEP module
4 eQEPCLK_EN R/W 1h
This bit controls the clk_en input to the eQEP module.
3-2 Reserved R 0h
1 eCAPCLKSTOP_REQ R/W 0h
This bit controls the clkstop_req input to the eCAP module.
0 eCAPCLK_EN R/W 1h
This bit controls the clk_en input to the eCAP module.
1492
Pulse-Width Modulation Subsystem (PWMSS) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
