www.ti.com
UART Registers
19.5.1.6 Interrupt Identification Register (IIR) - UART Mode
The UART interrupt identification register (IIR) is a read-only register that provides the source of the
interrupt. The UART interrupt identification register (IIR) is shown in Figure 19-39 and described in
Table 19-35.
NOTE: An interrupt source can be flagged only if enabled in the IER register.
Figure 19-39. UART Interrupt Identification Register (IIR)
15 8
Reserved
R-0
7 6 5 1 0
FCR_MIRROR IT_TYPE IT_PENDING
R-0 R-0 R-1
LEGEND: R = Read only; -n = value after reset
Table 19-35. UART Interrupt Identification Register (IIR) Field Descriptions
Bit Field Value Description
15-8 Reserved 0 Reserved.
7-6 FCR_MIRROR 0-3h Mirror the contents of FCR[0] on both bits.
5-1 IT_TYPE 0-1Fh Seven possible interrupts in UART mode; other combinations never occur:
0 Modem interrupt. Priority = 4.
1h THR interrupt. Priority = 3.
2h RHR interrupt. Priority = 2.
3h Receiver line status error. Priority = 1.
4h-5h Reserved
6h Rx timeout. Priority = 2.
7h Reserved
8h Xoff/special character. Priority = 5.
9h-Fh Reserved
10h CTS, RTS, DSR change state from active (low) to inactive (high). Priority = 6.
11h- Reserved
1Fh
0 IT_PENDING Interrupt pending.
0 An interrupt is pending.
1 No interrupt is pending.
3511
SPRUH73H–October 2011–Revised April 2013 Universal Asynchronous Receiver/Transmitter (UART)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
