Ethernet Subsystem Registers
www.ti.com
14.5.3.1 CPTS_IDVER Register (offset = 0h) [reset = 4E8A0101h]
CPTS_IDVER is shown in Figure 14-78 and described in Table 14-90.
IDENTIFICATION AND VERSION REGISTER
Figure 14-78. CPTS_IDVER Register
31 30 29 28 27 26 25 24
TX_IDENT
R-4E8Ah
23 22 21 20 19 18 17 16
TX_IDENT
R-4E8Ah
15 14 13 12 11 10 9 8
RTL_VER MAJOR_VER
R-9D140h R-4E8A01h
7 6 5 4 3 2 1 0
MINOR_VER
R-4E8A0101h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-90. CPTS_IDVER Register Field Descriptions
Bit Field Type Reset Description
31-16 TX_IDENT R 4E8Ah
TX Identification Value
15-11 RTL_VER R 9D140h
RTL Version Value
10-8 MAJOR_VER R 4E8A01h
Major Version Value
7-0 MINOR_VER R 4E8A0101h
Minor Version Value
1310
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
