Touchscreen Controller Registers
www.ti.com
12.5.1.12 ADCRANGE Register (offset = 48h) [reset = 0h]
ADCRANGE is shown in Figure 12-16 and described in Table 12-16.
High and Low Range Threshold@TSC_ADC_SS_Range_Check Register
Figure 12-16. ADCRANGE Register
31 30 29 28 27 26 25 24
Reserved High_Range_Data
R-0h R/W-0h
23 22 21 20 19 18 17 16
High_Range_Data
R/W-0h
15 14 13 12 11 10 9 8
Reserved Low_Range_Data
R-0h R/W-0h
7 6 5 4 3 2 1 0
Low_Range_Data
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-16. ADCRANGE Register Field Descriptions
Bit Field Type Reset Description
31-28 Reserved R 0h
27-16 High_Range_Data R/W 0h Sampled ADC data is compared to this value.
If the sampled data is greater than the value, then an interrupt is
generated.
15-12 Reserved R 0h
Reserved.
11-0 Low_Range_Data R/W 0h Sampled ADC data is compared to this value.
If the sampled data is less than the value, then an interrupt is
generated.
1050
Touchscreen Controller SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
