www.ti.com
USB Registers
16.5.5.6 RXHPCRA0 Register (offset = 80Ch) [reset = 0h]
RXHPCRA0 is shown in Figure 16-157 and described in Table 16-169.
Figure 16-157. RXHPCRA0 Register
31 30 29 28 27 26 25 24
Reserved RX_HOST_FDQ1_QMGR RX_HOST_FDQ1_QNUM
W-0h W-0h
23 22 21 20 19 18 17 16
RX_HOST_FDQ1_QNUM
W-0h
15 14 13 12 11 10 9 8
Reserved RX_HOST_FDQ0_QMGR RX_HOST_FDQ0_QNUM
W-0h W-0h
7 6 5 4 3 2 1 0
RX_HOST_FDQ0_QNUM
W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-169. RXHPCRA0 Register Field Descriptions
Bit Field Type Reset Description
29-28 RX_HOST_FDQ1_QMGR W 0h
This field specifies which Buffer Manager should be used for the
second Rx buffer in a host type packet.
27-16 RX_HOST_FDQ1_QNUM W 0h
This field specifies which Free Descriptor / Buffer Pool should be
used for the 2nd Rx buffer in a host type packet
13-12 RX_HOST_FDQ0_QMGR W 0h
This field specifies which Buffer Manager should be used for the
second Rx buffer in a host type packet.
11-0 RX_HOST_FDQ0_QNUM W 0h This field specifies which Free Descriptor / Buffer Pool should be
used for the 1st Rx buffer in a host type packet Table
100 -Rx Channel N Host Packet Configuration Registers A
1935
SPRUH73H–October 2011–Revised April 2013 Universal Serial Bus (USB)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
