Functional Description
www.ti.com
11.3.20 EDMA Events
Table 11-23. Direct Mapped
Event Number Event Name Source Module
0 pr1_host[7]
(1)
PRU-ICSS
1 pr1_host[6]
(1)
PRU-ICSS
2 SDTXEVT1 MMCHS1
3 SDRXEVT1 MMCHS1
4 Reserved Reserved
5 Reserved Reserved
6 Reserved Reserved
7 Reserved Reserved
8 AXEVT0 McASP0
9 AREVT0 McASP0
10 AXEVT1 McASP1
11 AREVT1 McASP1
12 Open Open
13 Open Open
14 ePWMEVT0 ePWM 0
15 ePWMEVT1 ePWM 1
16 SPIXEVT0 McSPI0
17 SPIREVT0 McSPI0
18 SPIXEVT1 McSPI0
19 SPIREVT1 McSPI0
20 Open Open
21 Open Open
22 GPIOEVT0 GPIO0
23 GPIOEVT1 GPIO1
24 SDTXEVT0 MMCHS0
25 SDRXEVT0 MMCHS0
26 UTXEVT0 UART0
27 URXEVT0 UART0
28 UTXEVT1 UART1
29 URXEVT1 UART1
30 UTXEVT2 UART2
31 URXEVT2 UART2
32 Open Open
33 Open Open
34 Open Open
35 Open Open
36 Open Open
37 Open Open
38 eCAPEVT0 eCAP 0
39 eCAPEVT1 eCAP 1
40 CAN_IF1DMA DCAN 0
41 CAN_IF2DMA DCAN 0
42 SPIXEVT0 McSPI1
43 SPIREVT0 McSPI1
44 SPIXEVT1 McSPI1
(1)
pr1_host_intr[0:7] corresponds to Host-2 to Host-9 of the PRU-ICSS interrupt controller.
936
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
