Ethernet Subsystem Registers www.ti.com
14.5.6.44 P2_SEND_PERCENT Register (offset = 228h) [reset = 0h]
P2_SEND_PERCENT is shown in Figure 14-164 and described in Table 14-179.
CPSW PORT 2 TRANSMIT QUEUE SEND PERCENTAGES
Figure 14-164. P2_SEND_PERCENT Register
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
Reserved PRI3_SEND_PERCENT
R/W-0h
15 14 13 12 11 10 9 8
Reserved PRI2_SEND_PERCENT
R/W-0h
7 6 5 4 3 2 1 0
Reserved PRI1_SEND_PERCENT
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-179. P2_SEND_PERCENT Register Field Descriptions
Bit Field Type Reset Description
22-16 PRI3_SEND_PERCENT R/W 0h Priority 3 Transmit Percentage - This percentage value is sent from
FIFO priority 3 (maximum) when the p1_pri3_shape_en is set
(queue shaping enabled).
This is the percentage of the wire that packets from priority 3 receive
(which includes interpacket gap and preamble bytes).
If shaping is enabled on this queue then this value must be between
zero and 0d100 (not inclusive).
14-8 PRI2_SEND_PERCENT R/W 0h Priority 2 Transmit Percentage - This percentage value is sent from
FIFO priority 2 (maximum) when the p1_pri2_shape_en is set
(queue shaping enabled).
This is the percentage of the wire that packets from priority 2 receive
(which includes interpacket gap and preamble bytes).
If shaping is enabled on this queue then this value must be between
zero and 0d100 (not inclusive).
6-0 PRI1_SEND_PERCENT R/W 0h Priority 1 Transmit Percentage - This percentage value is sent from
FIFO priority 1 (maximum) when the p1_pri1_shape_en is set
(queue shaping enabled).
This is the percentage of the wire that packets from priority 1 receive
(which includes interpacket gap and preamble bytes).
If shaping is enabled on this queue then this value must be between
zero and 0d100 (not inclusive).
