EDMA3 Registers
www.ti.com
11.4.1.6.7 Event Enable Set Registers (EESR, EESRH)
The event enable registers (EER/EERH) cannot be modified by directly writing to them. The intent is to
ease the software burden for the case where multiple tasks are attempting to simultaneously modify these
registers. The event enable set registers (EESR/EESRH) are used to enable events. Writes of 1 to the bits
in EESR/EESRH set the corresponding event bits in EER/EERH; writes of 0 have no effect.
The EESR is shown in Figure 11-82 and described in Table 11-66. The EESRH is shown in Figure 11-83
and described in Table 11-67.
Figure 11-82. Event Enable Set Register (EESR)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E31 E30 E29 E28 E27 E26 E25 E24 E23 E22 E21 E20 E19 E18 E17 E16
W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0
W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
LEGEND: W = Write only; -n = value after reset
Table 11-66. Event Enable Set Register (EESR) Field Descriptions
Bit Field Value Description
31-0 En Event enable set for events 0-31.
0 No effect.
1 Event is enabled. Corresponding bit in the event enable register (EER) is set (En = 1).
Figure 11-83. Event Enable Set Register High (EESRH)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E63 E62 E61 E60 E59 E58 E57 E56 E55 E54 E53 E52 E51 E50 E49 E48
W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E47 E46 E45 E44 E43 E42 E41 E40 E39 E38 E37 E36 E35 E34 E33 E32
W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 11-67. Event Enable Set Register High (EESRH) Field Descriptions
Bit Field Value Description
31-0 En Event enable set for events 32-63.
0 No effect.
1 Event is enabled. Corresponding bit in the event enable register high (EERH) is set (En = 1).
978
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
