EMIF
www.ti.com
7.3.5.1 EMIF_MOD_ID_REV Register (offset = 0h) [reset = 40440C03h]
EMIF_MOD_ID_REV is shown in Figure 7-91 and described in Table 7-111.
Figure 7-91. EMIF_MOD_ID_REV Register
31 30 29 28 27 26 25 24
reg_scheme Reserved reg_module_id
R-1h R-0h R-44h
23 22 21 20 19 18 17 16
reg_module_id
R-44h
15 14 13 12 11 10 9 8
reg_rtl_version reg_major_revision
R-1h R-4h
7 6 5 4 3 2 1 0
Reserved reg_minor_revision
R-0h R-3h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 7-111. EMIF_MOD_ID_REV Register Field Descriptions
Bit Field Type Reset Description
31-30 reg_scheme R 1h
Used to distinguish between old and current schemes.
29-28 Reserved R 0h
27-16 reg_module_id R 44h
EMIF module ID.
15-11 reg_rtl_version R 1h
RTL Version.
10-8 reg_major_revision R 4h
Major Revision.
7-6 Reserved R 0h
5-0 reg_minor_revision R 3h
Minor Revision.
424
Memory Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
