McASP Registers
www.ti.com
22.4.1.7 Pin Data Set Register (PDSET)
The pin data set register (PDSET) is an alias of the pin data output register (PDOUT) for writes only.
Writing a 1 to the PDSET bit sets the corresponding bit in PDOUT and, if PFUNC = 1 (GPIO function) and
PDIR = 1 (output), drives a logic high on the pin. PDSET is useful for a multitasking system because it
allows you to set to a logic high only the desired pin(s) within a system without affecting other I/O pins
controlled by the same McASP. The PDSET is shown in Figure 22-45 and described in Table 22-18.
CAUTION
Writing to Reserved Bits
Writing a value other than 0 to reserved bits in this register may cause improper
device operation.
Figure 22-45. Pin Data Set Register (PDSET)
31 30 29 28 27 26 25 24
AFSR AHCLKR ACLKR AFSX AHCLKX ACLKX AMUTE Reserved
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R-0
23 8
Reserved
R-0
7 6 5 4 3 2 1 0
Reserved AXR5 AXR4 AXR3 AXR2 AXR1 AXR0
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
3838
Multichannel Audio Serial Port (McASP) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
