www.ti.com
Power, Reset, and Clock Management
8.1.13.6.1 PM_RTC_PWRSTCTRL Register (offset = 0h) [reset = 4h]
PM_RTC_PWRSTCTRL is shown in Figure 8-187 and described in Table 8-207.
This register controls the RTC power state to reach upon mpu domain sleep transition
Figure 8-187. PM_RTC_PWRSTCTRL Register
31 30 29 28 27 26 25 24
Reserved Reserved
R-0h R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved LowPowerStateChang Reserved LogicRETState Reserved
e
R-0h R/W-0h R-0h R/W-1h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 8-207. PM_RTC_PWRSTCTRL Register Field Descriptions
Bit Field Type Reset Description
31-26 Reserved R 0h
25-16 Reserved R 0h
15-5 Reserved R 0h
4 LowPowerStateChange R/W 0h Power state change request when domain has already performed a
sleep transition.
Allows going into deeper low power state without waking up the
power domain.
0x0 = DIS : Do not request a low power state change.
0x1 = EN : Request a low power state change. This bit is
automatically cleared when the power state is effectively changed or
when power state is ON.
3 Reserved R 0h
2 LogicRETState R/W 1h
Logic state when power domain is RETENTION
0x0 = logic_off : Only retention registers are retained and remaing
logic is off when the domain is in RETENTION state.
0x1 = logic_ret : Whole logic is retained when domain is in
RETENTION state.
1-0 Reserved R 0h
737
SPRUH73H–October 2011–Revised April 2013 Power, Reset, and Clock Management (PRCM)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
