LCD Registers
www.ti.com
Table 13-36. IRQSTATUS Register Field Descriptions (continued)
Bit Field Type Reset Description
1 recurrent_raster_done_en R/W 0h Raster Frame Done Interrupt
_clr Read indicates enabled status
0 = Inactive
1 = Active
Writing 1 will clear interrupt enable
Writing 0 has no effect
0 done_en_clr R/W 0h Raster or LIDD Frame Done (shared, depends on whether Raster or
LIDD mode enabled) Enabled Interrupt and Clear Read indicates
enabled status 0 = inactive 1 = active Writing 1 will clear interrupt
enable
Writing 0 has no effect
