Ethernet Subsystem Registers
www.ti.com
Table 14-102. CPDMA_STATERAM REGISTERS (continued)
Offset Acronym Register Name Section
04h TX1_HDP CPDMA_STATERAM TX CHANNEL 1 HEAD DESC Section 14.5.5.2
POINTER *
08h TX2_HDP CPDMA_STATERAM TX CHANNEL 2 HEAD DESC Section 14.5.5.3
POINTER *
0Ch TX3_HDP CPDMA_STATERAM TX CHANNEL 3 HEAD DESC Section 14.5.5.4
POINTER *
10h TX4_HDP CPDMA_STATERAM TX CHANNEL 4 HEAD DESC Section 14.5.5.5
POINTER *
14h TX5_HDP CPDMA_STATERAM TX CHANNEL 5 HEAD DESC Section 14.5.5.6
POINTER *
18h TX6_HDP CPDMA_STATERAM TX CHANNEL 6 HEAD DESC Section 14.5.5.7
POINTER *
1Ch TX7_HDP CPDMA_STATERAM TX CHANNEL 7 HEAD DESC Section 14.5.5.8
POINTER *
20h RX0_HDP CPDMA_STATERAM RX 0 CHANNEL 0 HEAD DESC Section 14.5.5.9
POINTER *
24h RX1_HDP CPDMA_STATERAM RX 1 CHANNEL 1 HEAD DESC Section 14.5.5.10
POINTER *
28h RX2_HDP CPDMA_STATERAM RX 2 CHANNEL 2 HEAD DESC Section 14.5.5.11
POINTER *
2Ch RX3_HDP CPDMA_STATERAM RX 3 CHANNEL 3 HEAD DESC Section 14.5.5.12
POINTER *
30h RX4_HDP CPDMA_STATERAM RX 4 CHANNEL 4 HEAD DESC Section 14.5.5.13
POINTER *
34h RX5_HDP CPDMA_STATERAM RX 5 CHANNEL 5 HEAD DESC Section 14.5.5.14
POINTER *
38h RX6_HDP CPDMA_STATERAM RX 6 CHANNEL 6 HEAD DESC Section 14.5.5.15
POINTER *
3Ch RX7_HDP CPDMA_STATERAM RX 7 CHANNEL 7 HEAD DESC Section 14.5.5.16
POINTER *
40h TX0_CP CPDMA_STATERAM TX CHANNEL 0 COMPLETION Section 14.5.5.17
POINTER REGISTER
44h TX1_CP CPDMA_STATERAM TX CHANNEL 1 COMPLETION Section 14.5.5.18
POINTER REGISTER *
48h TX2_CP CPDMA_STATERAM TX CHANNEL 2 COMPLETION Section 14.5.5.19
POINTER REGISTER *
4Ch TX3_CP CPDMA_STATERAM TX CHANNEL 3 COMPLETION Section 14.5.5.20
POINTER REGISTER *
50h TX4_CP CPDMA_STATERAM TX CHANNEL 4 COMPLETION Section 14.5.5.21
POINTER REGISTER *
54h TX5_CP CPDMA_STATERAM TX CHANNEL 5 COMPLETION Section 14.5.5.22
POINTER REGISTER *
58h TX6_CP CPDMA_STATERAM TX CHANNEL 6 COMPLETION Section 14.5.5.23
POINTER REGISTER *
5Ch TX7_CP CPDMA_STATERAM TX CHANNEL 7 COMPLETION Section 14.5.5.24
POINTER REGISTER *
60h RX0_CP CPDMA_STATERAM RX CHANNEL 0 COMPLETION Section 14.5.5.25
POINTER REGISTER *
64h RX1_CP CPDMA_STATERAM RX CHANNEL 1 COMPLETION Section 14.5.5.26
POINTER REGISTER *
68h RX2_CP CPDMA_STATERAM RX CHANNEL 2 COMPLETION Section 14.5.5.27
POINTER REGISTER *
6Ch RX3_CP CPDMA_STATERAM RX CHANNEL 3 COMPLETION Section 14.5.5.28
POINTER REGISTER *
70h RX4_CP CPDMA_STATERAM RX CHANNEL 4 COMPLETION Section 14.5.5.29
POINTER REGISTER *
1322
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
