Enhanced PWM (ePWM) Module
www.ti.com
Table 15-46. EPWM1 Initialization for Figure 15-58
Register Bit Value Comments
TBPRD TBPRD 600 (258h) Period = 1200 TBCLK counts
TBPHS TBPHS 0 Clear Phase Register to 0
TBCTL CTRMODE TB_UPDOWN
PHSEN TB_DISABLE Phase loading disabled
PRDLD TB_SHADOW
SYNCOSEL TB_CTR_ZERO Sync down-stream module
CMPCTL SHDWAMODE CC_SHADOW
SHDWBMODE CC_SHADOW
LOADAMODE CC_CTR_ZERO Load on CTR = 0
LOADBMODE CC_CTR_ZERO Load on CTR = 0
AQCTLA CAU AQ_SET Set actions for EPWM1A
CAD AQ_CLEAR
AQCTLB CBU AQ_SET Set actions for EPWM1B
CBD AQ_CLEAR
Table 15-47. EPWM2 Initialization for Figure 15-58
Register Bit Value Comments
TBPRD TBPRD 600 (258h) Period = 1200 TBCLK counts
TBPHS TBPHS 0 Clear Phase Register to 0
TBCTL CTRMODE TB_UPDOWN
PHSEN TB_ENABLE Phase loading enabled
PRDLD TB_SHADOW
SYNCOSEL TB_SYNC_IN Sync flow-through
CMPCTL SHDWAMODE CC_SHADOW
SHDWBMODE CC_SHADOW
LOADAMODE CC_CTR_ZERO Load on CTR = 0
LOADBMODE CC_CTR_ZERO Load on CTR = 0
AQCTLA CAU AQ_SET Set actions for EPWM2A
CAD AQ_CLEAR
AQCTLB CBU AQ_SET Set actions for EPWM2B
CBD AQ_CLEAR
Example 15-4. Code Snippet for Configuration in Figure 15-58
// Run Time (Note: Example execution of one run-time instance)
//===========================================================
EPwm1Regs.CMPA.half.CMPA = 400; // adjust duty for output EPWM1A
EPwm1Regs.CMPB = 200; // adjust duty for output EPWM1B
EPwm2Regs.CMPA.half.CMPA = 500; // adjust duty for output EPWM2A
EPwm2Regs.CMPB = 300; // adjust duty for output EPWM2B
1564
Pulse-Width Modulation Subsystem (PWMSS) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
