Enhanced Capture (eCAP) Module
www.ti.com
Table 15-115. ECCTL1 Register Field Descriptions (continued)
Bit Field Type Reset Description
3 CTRRST2 R/W 0h
Counter Reset on Capture Event 2
0x0 = Do not reset counter on Capture Event 2 (absolute time
stamp)
0x1 = Reset counter after Event 2 time-stamp has been captured
(used in difference mode operation)
2 CAP2POL R/W 0h
Capture Event 2 Polarity select
0x0 = Capture Event 2 triggered on a rising edge (RE)
0x1 = Capture Event 2 triggered on a falling edge (FE)
1 CTRRST1 R/W 0h
Counter Reset on Capture Event 1
0x0 = Do not reset counter on Capture Event 1 (absolute time
stamp)
0x1 = Reset counter after Event 1 time-stamp has been captured
(used in difference mode operation)
0 CAP1POL R/W 0h
Capture Event 1 Polarity select
0x0 = Capture Event 1 triggered on a rising edge (RE)
0x1 = Capture Event 1 triggered on a falling edge (FE)
1642
Pulse-Width Modulation Subsystem (PWMSS) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
