Table 16-27. Queue-Endpoint Assignments (continued)
Queue Start Queue Count Queue-Endpoint Association
Number
40 2 USB0 Tx Endpoint 5
42 2 USB0 Tx Endpoint 6
44 2 USB0 Tx Endpoint 7
46 2 USB0 Tx Endpoint 8
48 2 USB0 Tx Endpoint 9
50 2 USB0 Tx Endpoint 10
52 2 USB0 Tx Endpoint 11
54 2 USB0 Tx Endpoint 12
56 2 USB0 Tx Endpoint 13
58 2 USB0 Tx Endpoint 14
60 2 USB0 Tx Endpoint 15
62 2 USB1 Tx Endpoint 1
64 2 USB1 Tx Endpoint 2
66 2 USB1 Tx Endpoint 3
68 2 USB1 Tx Endpoint 4
70 2 USB1 Tx Endpoint 5
72 2 USB1 Tx Endpoint 6
74 2 USB1 Tx Endpoint 7
76 2 USB1 Tx Endpoint 8
78 2 USB1 Tx Endpoint 9
80 2 USB1 Tx Endpoint 10
82 2 USB1 Tx Endpoint 11
84 2 USB1 Tx Endpoint 12
86 2 USB1 Tx Endpoint 13
88 2 USB1 Tx Endpoint 14
90 2 USB1 Tx Endpoint 15
92 1 Reserved
93 1 USB0 Tx Endpoint 1 completion queue
94 1 USB0 Tx Endpoint 2 completion queue
95 1 USB0 Tx Endpoint 3 completion queue
96 1 USB0 Tx Endpoint 4 completion queue
97 1 USB0 Tx Endpoint 5 completion queue
98 1 USB0 Tx Endpoint 6 completion queue
99 1 USB0 Tx Endpoint 7 completion queue
100 1 USB0 Tx Endpoint 8 completion queue
101 1 USB0 Tx Endpoint 9 completion queue
102 1 USB0 Tx Endpoint 10 completion queue
103 1 USB0 Tx Endpoint 11 completion queue
104 1 USB0 Tx Endpoint 12 completion queue
104 1 USB0 Tx Endpoint 13 completion queue
106 1 USB0 Tx Endpoint 14 completion queue
107 1 USB0 Tx Endpoint 15 completion queue
108 1 Reserved
109 1 USB0 Rx Endpoint 1 completion queue
110 1 USB0 Rx Endpoint 2 completion queue
111 1 USB0 Rx Endpoint 3 completion queue
112 1 USB0 Rx Endpoint 4 completion queue
