USB Registers
Table 16-86. USB0RXMODE Register Field Descriptions (continued)
Bit Field Type Reset Description
11-10 RX6_MODE R/W 0h 00: Transparent Mode on RX endpoint 5
01: RNDIS Mode on RX endpoint 5
10: CDC Mode on RX endpoint 5
11: Generic RNDIS or Infinite Mode on RX endpoint 5
9-8 RX5_MODE R/W 0h 00: Transparent Mode on RX endpoint 4
01: RNDIS Mode on RX endpoint 4
10: CDC Mode on RX endpoint 4
11: Generic RNDIS or Infinite Mode on RX endpoint 4
7-6 RX4_MODE R/W 0h 00: Transparent Mode on RX endpoint 3
01: RNDIS Mode on RX endpoint 3
10: CDC Mode on RX endpoint 3
11: Generic RNDIS or Infinite Mode on RX endpoint 3
5-4 RX3_MODE R/W 0h 00: Transparent Mode on RX endpoint 2
01: RNDIS Mode on RX endpoint 2
10: CDC Mode on RX endpoint 2
11: Generic RNDIS or Infinite Mode on RX endpoint 2
3-2 RX2_MODE R/W 0h 00: Transparent Mode on RX endpoint 1
01: RNDIS Mode on RX endpoint 1
10: CDC Mode on RX endpoint 1
11: Generic RNDIS or Infinite Mode on RX endpoint 1
1829
SPRUH73H–October 2011–Revised April 2013 Universal Serial Bus (USB)
