Hardware
SOC Peripheral Module
Step 1
M_IRQ_n Asserted
MPU INTC
If the IRQ_n is not masked and configured as an IRQ/FIQ,
the MPU_INTC_IRQ/MPU_INTC_FIQ line is asserted.
Step 2
MPU_INTC_IRQ/
MPU_INTC_FIQ Asserted
ARM Host Processor (Step 4)
If FIQs are enabled (F==0):
Finish the current instruction number N
Store address of next instruction to be
executed in the Link Register
Save CPSR before execution in the SPSR
Enter ARM FIQ mode
Disable IRQs and FIQs at ARM side
Execute the interrupt vector.
?
?
?
?
?
?
Software
Main Program
?
?
Execution of instruction number 1
Execution of instruction number N
ISR in IRQ/FIQ Mode (Step 5)
?
?
?
Save ARM critical context
Identify interrupt source
Branch to relevant interrupt subroutine handler
Relevant Subroutine Handler in IRQ/FIQ Mode (Step 6)
?
?
Handles the event (functional procedure)
Deassert the interrupt M_IRQ_n at SOC peripheral
module side.
ISR in IRQ/FIQ Mode (Step 7)
?
?
Allow a new IRQ/FIQ at INTC side by setting the
NEWIRQAGR/NEWFIQAGR bit to 1.
Restore ARM critical context.
Main Program
? Execution of instruction number N + 1
ARM Host Processor (Step 8)
?
?
Restore the whole CPSR
Restore the PC
Branch
Branch
Branch
Return
Return
