Multimedia Card Registers

www.ti.com

Table 18-40. SD_ISE Register Field Descriptions (continued)

Bit Field Type Reset Description

2 BGE_SIGEN R/W 0h

Block gap event signal status enable

0x0 = Masked

0x1 = Enabled

1 TC_SIGEN R/W 0h

Transfer completed signal status enable

0x0 = Masked

0x1 = Enabled

0 CC_SIGEN R/W 0h

Command completed signal status enable

0x0 = Masked

0x1 = Enabled

3434

Multimedia Card (MMC) SPRUH73H–October 2011–Revised April 2013

Submit Documentation Feedback
