DMTimer
www.ti.com
Table 20-19. TCLR Register Field Descriptions (continued)
Bit Field Type Reset Description
5 PRE R/W 0h
Prescaler enable
0x0 = The TIMER clock input pin clocks the counter
0x1 = The divided input pin clocks the counter
4-2 PTV R/W 0h
Pre-scale clock Timer value
1 AR R/W 0h
0x0 = One shot timer
0x1 = Auto-reload timer
0 ST R/W 0h
In the case of one-shot mode selected (AR = 0), this bit is
automatically reset by internal logic when the counter is overflowed.
0x0(READ) = Stop timeOnly the counter is frozen
0x1 = Start timer
