Functional Description www.ti.com
Table 22-7. Channel Status and User Data for Each DIT Block
Frame Subframe Preamble Channel Status defined in: User Data defined in:
Defined by DITCSRA0, DITCSRB0, DITUDRA0, DITUDRB0
0 1 (L) B DITCSRA0[0] DITUDRA0[0]
0 2 (R) W DITCSRB0[0] DITUDRB0[0]
1 1 (L) M DITCSRA0[1] DITUDRA0[1]
1 2 (R) W DITCSRB0[1] DITUDRB0[1]
2 1 (L) M DITCSRA0[2] DITUDRA0[2]
2 2 (R) W DITCSRB0[2] DITUDRB0[2]
… … … … …
31 1 (L) M DITCSRA0[31] DITUDRA0[31]
31 2 (R) W DITCSRB0[31] DITUDRB0[31]
Defined by DITCSRA1, DITCSRB1, DITUDRA1, DITUDRB1
32 1 (L) M DITCSRA1[0] DITUDRA1[0]
32 2 (R) W DITCSRB1[0] DITUDRB1[0]
… … … … …
63 1 (L) M DITCSRA1[31] DITUDRA1[31]
63 2 (R) W DITCSRB1[31] DITUDRB1[31]
Defined by DITCSRA2, DITCSRB2, DITUDRA2, DITUDRB2
64 1 (L) M DITCSRA2[0] DITUDRA2[0]
64 2 (R) W DITCSRB2[0] DITUDRB2[0]
… … … … …
95 1 (L) M DITCSRA2[31] DITUDRA2[31]
95 2 (R) W DITCSRB2[31] DITUDRB2[31]
Defined by DITCSRA3, DITCSRB3, DITUDRA3, DITUDRB3
96 1 (L) M DITCSRA3[0] DITUDRA3[0]
96 2 (R) W DITCSRB3[0] DITUDRB3[0]
… … … … …
127 1 (L) M DITCSRA3[31] DITUDRA3[31]
127 2 (R) W DITCSRB3[31] DITUDRB3[31]
Defined by DITCSRA4, DITCSRB4, DITUDRA4, DITUDRB4
128 1 (L) M DITCSRA4[0] DITUDRA4[0]
128 2 (R) W DITCSRB4[0] DITUDRB4[0]
… … … … …
159 1 (L) M DITCSRA4[31] DITUDRA4[31]
159 2 (R) W DITCSRB4[31] DITUDRB4[31]
Defined by DITCSRA5, DITCSRB5, DITUDRA5, DITUDRB5
160 1 (L) M DITCSRA5[0] DITUDRA5[0]
160 2 (R) W DITCSRB5[0] DITUDRB5[0]
… … … … …
191 1 (L) M DITCSRA5[31] DITUDRA5[31]
191 2 (R) W DITCSRB5[31] DITUDRB5[31]
3794
Multichannel Audio Serial Port (McASP) SPRUH73H–October 2011–Revised April 2013
