Texas Instruments AM335 Series Technical Reference Manual

www.ti.com McASP Registers
Table 22-19. Pin Data Clear Register (PDCLR) Field Descriptions
Bit Field Value Description
31 AFSR Allows the corresponding AFSR bit in PDOUT to be cleared to a logic low without affecting other I/O pins
controlled by the same port.
0 No effect.
1 PDOUT[31] bit is cleared to 0.
30 AHCLKR Allows the corresponding AHCLKR bit in PDOUT to be cleared to a logic low without affecting other I/O
pins controlled by the same port.
0 No effect.
1 PDOUT[30] bit is cleared to 0.
29 ACLKR Allows the corresponding ACLKR bit in PDOUT to be cleared to a logic low without affecting other I/O
pins controlled by the same port.
0 No effect.
1 PDOUT[29] bit is cleared to 0.
28 AFSX Allows the corresponding AFSX bit in PDOUT to be cleared to a logic low without affecting other I/O pins
controlled by the same port.
0 No effect.
1 PDOUT[28] bit is cleared to 0.
27 AHCLKX Allows the corresponding AHCLKX bit in PDOUT to be cleared to a logic low without affecting other I/O
pins controlled by the same port.
0 No effect.
1 PDOUT[27] bit is cleared to 0.
26 ACLKX Allows the corresponding ACLKX bit in PDOUT to be cleared to a logic low without affecting other I/O
pins controlled by the same port.
0 No effect.
1 PDOUT[26] bit is cleared to 0.
25 AMUTE Allows the corresponding AMUTE bit in PDOUT to be cleared to a logic low without affecting other I/O
pins controlled by the same port.
0 No effect.
1 PDOUT[25] bit is cleared to 0.
24-6 Reserved 0 Reserved. The reserved bit location always returns the default value. A value written to this field has no
effect. If writing to this field, always write the default value for future device compatibility.
5-0 AXR[5-0] Allows the corresponding AXR[n] bit in PDOUT to be cleared to a logic low without affecting other I/O
pins controlled by the same port.
0 No effect.
1 PDOUT[n] bit is cleared to 0.
3841
SPRUH73H–October 2011–Revised April 2013 Multichannel Audio Serial Port (McASP)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
