t
ADVon
t
ADVoff
t
wr rd
,
t
t
OEon WEon
,
t
t
WEoff
t
OEoff
CS0
OE
WE
ADV
t
CEoff
t
rddata
t
CEon
Functional Description
www.ti.com
Figure 26-9. GPMC XIP Timings
Table 26-8. XIP Timings Parameters
Parameter Description Value [clock cycles]
t
wr
write cycle period 17
t
rd
read cycle period 17
t
CEon
CE low time 1
t
CEoff
CE high time 16
t
ADVon
ADV low time 1
t
ADVoff
ADV high time 2
t
OEon
OE low time 3
t
WEon
WE low time 3
t
rddata
data latch time 15
t
OEoff
OE high time 16
t
WEoff
WE high time 15
4116
Initialization SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
