Functional Description
www.ti.com
Table 26-41. Tracing Vectors (continued)
Trace vector Bit No. Group Meaning
1 15 Peripheral Boot Peripheral booting failed
Booting Message not received
1 16 Peripheral Boot
(timeout)
Image size not received
1 17 Peripheral Boot
(timeout)
1 18 Peripheral Boot Image not received (timeout)
1 19 Reserved Reserved
1 20 Configuration Header CHSETTINGS found
1 21 Configuration Header CHSETTINGS executed
1 22 Configuration Header CHRAM executed
1 23 Configuration Header CHFLASH executed
1 24 Configuration Header CHMMCSD clocks executed
CHMMCSD bus width
1 25 Configuration Header
executed
1 26 Reserved Reserved
1 27 Reserved Reserved
1 28 Reserved Reserved
1 29 Reserved Reserved
1 30 Reserved Reserved
1 31 Reserved Reserved
2 0 Companion chip Reserved
2 1 Companion chip Reserved
2 2 Companion chip Reserved
2 3 Companion chip Reserved
2 4 USB USB connect
2 5 USB USB configured state
2 6 USB USB VBUS valid
2 7 USB USB session valid
2 8 Reserved Reserved
2 9 Reserved Reserved
2 10 Reserved Reserved
2 11 Reserved Reserved
2 12 Memory Boot Memory booting trial 0
2 13 Memory Boot Memory booting trial 1
2 14 Memory Boot Memory booting trial 2
2 15 Memory Boot Memory booting trial 3
2 16 Memory Boot Execute GP image
Start authentication of
2 17 Peripheral Boot
peripheral boot image
2 18 Memory & Peripheral Boot Jumping to Initial SW
2 19 Memory & Peripheral Boot Reserved
2 20 Memory & Peripheral Boot Start image authentication
2 21 Memory & Peripheral Boot Image authentication failed
2 22 Memory & Peripheral Boot Analyzing SpeedUp
2 23 Memory & Peripheral Boot Speedup failed
2 24 Memory & Peripheral Boot Reserved
2 25 Memory & Peripheral Boot Reserved
2 26 Memory & Peripheral Boot Reserved
2 27 Memory & Peripheral Boot Reserved
4154
Initialization SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
