Functional Description
www.ti.com
Figure 27-1. Suspend Control Registers
31 8 7 4 3 2 1 0
Reserved Suspend_Sel Suspend_Default_ Reserved Sens
override Ctrl
R-0h R/W-0h R/W-0h R-0h R/W-
0h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 27-2. Suspend Control Registers Field Descriptions
Bit Field Value Description
31 Reserved 0
7-4 Suspend_Sel
Suspend signal selection.
Selects which suspend signal affects the peripheral. Only valid when Suspend_Default_Override=0
and SensCtrl=1.
When read, these bits reflect the default suspend signal.
0000b: Cortex-A8 suspend signal.
All other values are reserved.
3 Suspend_Default 0 Enable/Disable the override value in Suspend_Sel.
_Override
0: Suspend_Sel field will select which suspend signal reaches the peripheral.
1: Suspend_Sel field ignored. Default suspend signal will reach the peripheral.
2-1 Reserved 0
0 SensCtrl 0
Sensitivity Control for suspend signals.
When Suspend_Default_Override=1, this bit is ignored and read as a 1.
When Suspend_Default_Override=0:
0: Suspend signal will not reach the peripheral. Peripheral will act as normal even during a debug
halt.
1: Suspend signal will reach the peripheral. Peripheral will be suspended during debug halt.
4158
Debug Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
