Enhanced PWM (ePWM) Module
www.ti.com
Table 15-50. EPWM1 Initialization for Figure 15-62
Register Bit Value Comments
TBPRD TBPRD 800 (320h) Period = 1600 TBCLK counts
TBPHS TBPHS 0 Clear Phase Register to 0
TBCTL CTRMODE TB_UPDOWN
PHSEN TB_DISABLE Phase loading disabled
PRDLD TB_SHADOW
SYNCOSEL TB_CTR_ZERO Sync down-stream module
CMPCTL SHDWAMODE CC_SHADOW
SHDWBMODE CC_SHADOW
LOADAMODE CC_CTR_ZERO Load on CTR = 0
LOADBMODE CC_CTR_ZERO Load on CTR = 0
AQCTLA CAU AQ_SET Set actions for EPWM1A
CAD AQ_CLEAR
DBCTL MODE DB_FULL_ENABLE Enable Dead-band module
POLSEL DB_ACTV_HIC Active Hi complementary
DBFED DBFED 50 FED = 50 TBCLKs
DBRED 50 RED = 50 TBCLKs
Table 15-51. EPWM2 Initialization for Figure 15-62
Register Bit Value Comments
TBPRD TBPRD 800 (320h) Period = 1600 TBCLK counts
TBPHS TBPHS 0 Clear Phase Register to 0
TBCTL CTRMODE TB_UPDOWN
PHSEN TB_ENABLE Slave module
PRDLD TB_SHADOW
SYNCOSEL TB_SYNC_IN Sync flow-through
CMPCTL SHDWAMODE CC_SHADOW
SHDWBMODE CC_SHADOW
LOADAMODE CC_CTR_ZERO Load on CTR = 0
LOADBMODE CC_CTR_ZERO Load on CTR = 0
AQCTLA CAU AQ_SET Set actions for EPWM2A
CAD AQ_CLEAR
DBCTL MODE DB_FULL_ENABLE Enable Dead-band module
POLSEL DB_ACTV_HIC Active Hi complementary
DBFED DBFED 50 FED = 50 TBCLKs
DBRED 50 RED = 50 TBCLKs
1570
Pulse-Width Modulation Subsystem (PWMSS) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
