0x20000

0x2BFFF

ROM Exc. Vectors

Dead loops

Public ROM CRC

0x20080

0x20020

Code

0x20100

ROM Version

0x2BFFC

Functional Description

www.ti.com

Figure 26-3. ROM Memory Map

Public ROM Exception Vectors

Table 26-1 lists the Public ROM exception vectors. The reset exception is redirected to the Public ROM

Code startup. Other exceptions are redirected to their RAM handlers by loading appropriate addresses

into the PC register.

4098

Initialization SPRUH73H–October 2011–Revised April 2013

Submit Documentation Feedback
